Remote starters are a game changer in the automotive industry giving drivers the ease of starting their vehicle without leaving the comfort of their home. Remote starters are designed to start your vehicle while you are still inside your home, office, or a store, and have your car ready to go without having to wait in the cold or hot weather. However, installing a remote starter can be a bit tricky because of the wiring involved. Therefore, this article will provide you with vehicle wiring diagrams for remote starts that will help you install your remote starter with ease.
What is a Remote Starter?
A remote starter is a device that allows you to start your vehicle’s engine from a distance. The device comes with a remote that enables you to start your vehicle and warm up the engine or cool down the interior before entering the car. Remote starters come in different types, including OEM remote starters, which are integrated into your vehicle’s factory key fob, or aftermarket remote starters, which come as an additional device that can be mounted onto your key fob or installed separately.
How Does a Remote Starter Work?
A remote starter works by sending a signal to the vehicle’s computer to start the engine. The signal is sent through the vehicle’s electrical system, which is why proper wiring is essential when installing a remote starter. The remote starter consists of two main components, the transmitter, and the receiver. The transmitter is the remote that you use to start the engine, while the receiver is the device that receives the signal and starts the engine.
What Are the Benefits of a Remote Starter?
There are many benefits of a remote starter, including:
| Benefits of Remote Starter |
|---|
| 1. Saves Time |
| 2. Saves Energy |
| 3. Increases Safety |
| 4. Enhances Comfort |
| 5. Prolongs Engine Lifetime |
Vehicle Wiring Diagrams for Remote Starts
Nowadays, most vehicles come with sophisticated electrical systems, which can make installing a remote starter a bit complicated. However, with the right tools and knowledge, anyone can install a remote starter. Below are vehicle wiring diagrams for remote starts that will guide you on how to install a remote starter.
1. General Wiring Diagram
The general wiring diagram for most remote starters includes six wires, which are:
| Wire Color | Description |
|---|---|
| Red/Black | 12V Power Source |
| Red | Accessory Ignition |
| Yellow | Starter Output |
| Orange | Accessory 1 |
| Orange/White | Accessory 2 |
| Black/White | Ground |
Wire the six wires as follows:
- Connect the red/black wire to a 12V power source, usually the battery or fuse box.
- Connect the red wire to the accessory ignition wire under the steering column.
- Connect the yellow wire to the starter output wire, which is usually located near the ignition switch.
- Connect the orange wire to the accessory 1, usually the radio power wire.
- Connect the orange/white wire to the accessory 2, usually the power door lock wire.
- Connect the black/white wire to a ground point on the vehicle, usually the chassis.
2. Vehicle Specific Wiring Diagrams
If you are not familiar with your vehicle’s electrical system, it is best to use vehicle-specific wiring diagrams for remote starts. These diagrams provide detailed information on how to install a remote starter in your vehicle’s make and model.
You can find vehicle-specific wiring diagrams online or through the remote starter manufacturer. Vehicle-specific wiring diagrams provide detailed information on wiring color codes, wire placement, and other specific details essential for the installation process.
FAQ About Vehicle Wiring Diagrams for Remote Starts
Q: Can I install a remote starter myself?
A: Yes, you can install a remote starter yourself if you have the necessary knowledge, tools, and patience. However, it is best to seek professional help if you are not familiar with the electrical system of your vehicle.
Q: How much does remote starter installation cost?
A: The cost of a remote starter installation varies depending on your vehicle’s make and model and the type of remote starter you want to install. However, the average cost ranges between $200 to $500.
Q: Can a remote starter damage my vehicle?
A: No, a remote starter will not damage your vehicle if installed correctly. However, improper installation can lead to electrical problems or damage to your vehicle’s computer, which can be costly to repair.
Q: Can I use my OEM key fob to operate a remote starter?
A: Yes, some remote starters are designed to integrate with your vehicle’s factory key fob, which allows you to use your factory key fob to operate the remote starter.
Q: Can I install a remote starter on a manual transmission vehicle?
A: Yes, you can install a remote starter on a manual transmission vehicle. However, it is essential to use a remote starter designed for manual transmission vehicles to prevent accidents.
Conclusion
Remote starters are an excellent addition to any vehicle and are designed to make your life easier. However, installing a remote starter can be complicated, and wiring is the most important aspect to consider. This article has provided you with vehicle wiring diagrams for remote starts that will help you install your remote starter with ease. Remember, if you are not familiar with your vehicle’s electrical system, it is best to seek professional help.
