The Ford Expedition is a full-size SUV that has been in production since 1997. Over the years, it has received several updates and improvements, and the latest generations come with a host of advanced features and technologies. However, like many other vehicles, the Expedition is not immune to electrical problems and faults, and one of the most common issues that owners face is blown fuses. In this article, we will provide you with a detailed Ford Expedition fuse panel diagram to help you identify and fix any electrical problems that you may encounter.
What is a Fuse Panel?
A fuse panel, also known as a fuse box or fuse block, is an electrical control center that contains a series of fuses to protect the circuits in a vehicle from damage due to electrical surges or faults. Fuses are designed to blow when there is too much current flowing through a circuit, preventing the electrical components from getting damaged. Each fuse is sized to match the current rating of the circuit it protects, and they are color-coded to make it easy to identify the amp rating.
In the Ford Expedition, the fuse panel is located under the steering wheel on the driver’s side of the vehicle. It is labeled with a plastic cover that snaps off to reveal the fuses and the corresponding amperage ratings. There are two fuse panels in the Expedition, one in the engine compartment and another one inside the cabin. In this article, we will focus on the interior fuse box.
Interior Fuse Box Diagram
The interior fuse box in the Ford Expedition is located on the right-hand side of the instrument panel. It is behind the access panel on the passenger’s side of the dashboard. The fuse panel diagram is printed on the cover of the fuse box. The following table shows the location and function of each fuse in the interior fuse box:
| Fuse | Location | Function |
|---|---|---|
| 1 | Cigar lighter | – |
| 2 | Instrument cluster | – |
| 3 | Trailer tow battery charge | – |
| 4 | Radio (start signal) | – |
| 5 | Adjustable pedal | – |
| 6 | Parking brake pedal | – |
| 7 | Powertrain control module | – |
| 8 | High beams | – |
| 9 | Horn | – |
| 10 | Daytime running lamps | – |
| 11 | Climate control | – |
| 12 | Power mirror | – |
| 13 | Trailer tow park lamps | – |
| 14 | Reverse camera | – |
| 15 | Heads up display | – |
| 16 | Transmission control switch | – |
| 17 | Rear wiper motor | – |
| 18 | Driver power seat | – |
| 19 | Passenger power seat | – |
| 20 | Power door locks | – |
| 21 | Trailer tow stop and turn | – |
| 22 | Subwoofer amplifier | – |
| 23 | Power windows | – |
| 24 | Trailer tow back-up lamps | – |
| 25 | Interior lighting | – |
| 26 | Trailer tow battery charge | – |
| 27 | Power point | – |
| 28 | Memory seat | – |
| 29 | Run/start relay | – |
| 30 | Trailer tow battery charge | – |
Frequently Asked Questions
Q: What should I do if a fuse blows?
A: If a fuse blows, you should first identify the cause of the problem before replacing the fuse. Check the electrical component or circuit that the fuse protects to see if there are any signs of damage or malfunction. If everything seems to be working fine, you can replace the blown fuse with a new one of the same amperage rating. It is important to use the correct size and type of fuse to avoid creating a fire hazard or damaging the electrical system.
Q: Can I replace a fuse with a higher amp rating?
A: No, you should never replace a fuse with a higher amp rating than what is specified in the fuse panel diagram. Using a higher-rated fuse can overload the circuit and cause damage to the electrical components or even start a fire. Always use the correct size and type of fuse recommended by the manufacturer.
Q: How do I know if a fuse is blown?
A: There are a few signs that indicate a blown fuse, such as a non-functioning electrical component, a fuse that has a melted or broken wire, or a fuse that is discolored or has a burnt smell. You can also use a multimeter to test the continuity of the fuse and check if it is functioning properly.
Q: Can I drive my car if a fuse is blown?
A: It depends on which circuit the blown fuse protects. If it is a circuit that is essential for the safe operation of the vehicle, such as the headlights or the brake lights, it is not safe to drive with a blown fuse. However, if it is a non-essential circuit, such as the power windows or the radio, it may be possible to drive the car until you can replace the fuse.
Q: What tools do I need to replace a fuse?
A: All you need to replace a fuse is a set of pliers or a fuse puller, which is usually included in the fuse box. Make sure to choose the correct size and type of fuse before replacing it, and always follow the instructions provided by the manufacturer.
With this Ford Expedition fuse panel diagram and the information provided in this article, you should now be able to diagnose and fix any electrical problems that you may encounter. Remember to always handle fuses with care and use the proper safety precautions when working on your vehicle’s electrical system.
